Deep Drawing & Metal Fabrication

We have 14 years of experience deep drawing metal. Our facility in Shenzhen , We have the expertise to solve your most complicated metal drawing needs — and we deliver shorter lead times, higher quality & lower costs!

Deep Drawing

Shenzhen jiarun precision stamping mould company is a leading manufacturer of deep drawn parts, including cylinders, enclosures and irregular shapes. We maintain a vertically-integrated facility with on-site engineering, designing, and prototyping services. Over the last 14 years, we've earned a reputation for producing highly complex, yet cost-effective, deep drawn parts.

Sizes: We start with blanks up to 100mm in diameter and make deep drawn parts ranging from ½"-24" wide with depths up to 24"

Materials: Aluminum, brass, bronze, copper, mu-metal, nickel, stainless steel, steel, titanium, & specialty metals

Secondary Operations: Anodizing, assembling, blanking, CNC machining, dip brazing, forming, iriditing, heat treating, Heliarc® welding, painting (wet & powder), piercing, spinning, spot welding, trimming & swedging.

Return to top

Deep Drawing Process

The first step in manufacturing a deep drawn part is choosing the alloy. Our expert engineers can help you select the best metal for your application. We can also source metal for you or use sheet metal or rolled metal you already own. We then cut the metal down to 48" diameter blanks.

The next step is preparing the blanks. Our engineers take great care to prepare each metal blank according to its properties, which maintains the integrity of the alloy and prevents cracks and tears in the finished product.

Once the blank is prepared, the deep drawn part is formed by drawing the metal blank around a punch as it's pulled through a die. The edges of the metal blank are restrained by a blank holder or sleeve.

A key benefit of deep drawing, compared to hydroforming, is the ability to perform multiple re-draws. Each draw can produce a 43% reduction of the metal blank. Greater depths — up to 24" — can be achieved through multiple draws, which reduce the diameter and increase the height of the previously drawn shell.

If you are wondering if JR can deep draw your part, take a look at our Deep Drawn Parts Gallery to get a sense of our capabilities.

Return to top

Benefits of Deep Drawing

When you choose JR as your manufacturer of deep drawn parts, you get:

Design & Engineering Expertise: We've been manufacturing complex, seamless metal shapes — including cylinders, boxes, enclosures, and irregular formations — for 100 years. Our experts know exactly how to prepare and handle each alloy, and our zero defects policy ensures complete customer satisfaction.

Reliable Customer Service: Our expert engineers are available to help you with each step of the process, from finalizing your CAD drawings, to choosing and souring the alloy, to selecting the secondary operations you need.

Value-Added Services: We perform many secondary operations on-site, from assembling deep drawn parts to blanking, welding, and finishing. Doing it all in-house generally results in cost savings, fewer defects, higher quality finished pieces and less paperwork (single purchase orders).

Contact JR's engineering support team as early as possible in your product development process. We can help you save money on tooling and production costs, while also delivering shorter lead times than the competition. Send us your CAD drawings today, and our expert engineers will help you get started.

Return to top

Deep Draw / Deep Drawing Considerations

Common shapes for Deep Drawn / Deep Draw parts are cans, boxes, and bottles, as well as irregularly shaped products.

Deep Drawing / Deep Draw can achieve a 43% reduction. Numerous re-draws can be performed on deep drawn parts to attain the desired depth.

The tooling for Deep Drawing / Deep Draw requires a punch, die and blank holder. Therefore, if cost is a factor in the design/manufacture of your part we invite you to contact Amalco's engineering support team to confirm Deep Drawing is the best solution prior to completing your design. We may be able to offer you an alternative process which can lower costs.

Return to top

Quality System (Conforms to MIL-I-45208)

With our MIL-Grade Quality System , our commercial customers enjoy the same critical quality control standards that have allowed us to deliver Defense Department contracted products for many years. Amalco employs the latest technologies in its QC inspection processes, and maintains its own QC Manual focused on a goal of "Zero Defects on All Products Produced."

Deep Drawn Aluminum Boxes & Covers

Aluminum boxes and covers manufactured to your specifications, including custom designs, sizes, and configurations. We maintain stock tooling to manufacture hundreds of typical sizes and configurations of rectangular aluminum boxes, enclosures, and covers.

Use our convenient Aluminum Boxes and Covers Buyer's Guide to specify and order your aluminum parts by outside width, outside length, maximum overall height, inside corner radius, inside bottom radius, thickness, and cover fitting requirements. Government certifications on specifications are available upon request where applicable.

Deep Drawn Cans

Deep drawing is used to produce seamless metal enclosures such as cans, boxes, and bottles, as well as irregular shaped products. Deep drawing requires tooling, including a punch, die, and blank holder. A punch is pressed against a material blank and the material is drawn through the die to form the desired shape.

Deep drawing can achieve up to 43% reduction on a metal blank, and multiple successive deep draws can be used to achieve part size or shape requirements. A variety of metals can be deep drawn, including aluminum, stainless steel, aluminized steel, cold rolled steel, brass, bronze, cupro nickel, nickel, and titanium.

Use our convenient Aluminum Cans Buyer's Guide to specify and order your aluminum parts by outside diameter, maximum overall height, inside radius, and blank thickness requirements.

Return to top

ARINC Cans - Square Aluminum Enclosures for Aircraft Electronic Instrumentation

ARINC (Aeronautical Radio, Incorporated) was chartered by the US Government (Federal Radio Commission, now Federal Communications Commission) to coordinate non-governmental radio communications. ARINC developed standards for interchangeable trays and boxes used to enclose standard line-replaceable units (like radios) in aircraft (known as ARINC electronics enclosures, or ARIN cans). ARINC square avionics instrumentation mounts are designed to be lightweight, and to enable the rapid exchange of on board electronics components without complex fasteners, connectors, or the need for special tools or test equipment.

Amalco delivers aluminum deep drawn aircraft instrument cases and electronics enclosures in both standard and special (custom) designs and sizes, meeting dimensional requirements for ARINC Specification Number 408A . The deep drawn process ensures exact tolerances, meeting ARINC requirements and your specifications.

Amalco provides complete in-house facilities for fabrication of ARINC cans to your specifications, made from 0.050" thick 3003-0 Aluminum (6061 optional). Piercing, attachments, and other secondary operations are performed in-house, saving you paperwork and procurement processing time (single authorization) while ensuring strict quality control from raw material through finished product. Brazed assemblies, dip-brazing and finishing (including alodine or anodize and paint) are also performed in-house at Amalco's Mountainside, New Jersey facility. Contact Amalco for your ARINC cans and mounts.

Use our convenient ARINC Brochure to specify and order your aluminum parts by alloy and reference number.

Return to top

Deep Drawing and Secondary Operations

Deep Drawing can be a multi-draw operation performed on a specially prepared metal blank. Deep Drawying can be followed by secondary operations which range from custom fabrication to light assemble to finishing.

Amalco is uniquely equipped to perform a full range of secondary operations including: spinning, stamping, and CNC machining all in one facility. Heliarc welding, spot welding, riveting, brazing (dip-brazing), heat treating, anodizing and painting performed on-site as one purchase order under one comprehensive quality assurance program, in our clean and efficient facility. Our integrated process results in shorter lead times and lower costs for most customers.

About our product feature:

1.All punch chip use tungsten steel to stamping , The comprehensive service life span of the tool is not less than ten million stamping times. Tungsten steel edge should be grinded within 2 million stampings per time. but any details according to customer reuquires.

2.all price will precision count by my engineer and provide a competitive price for my customer. let all product have good value for money.

3.Consider to convenience,it's simple assembly to our mould.and lower cost for maintenance , special after-sales service and  regular maintenance and  grind punch chip.


4. we have a experienced design and manufacture team. and it's important to each details for us. we very care the finally and key requires. the good quality and warm service always  promise and  practice to my customers. meanwhile, we won the  affirmation and trust of them.

5.we can provide design drawings 2D and 3D files to my customers. and technology support.

6. we have complete test system and instrument. and Issued quality inspection sheet by Jiarun Quality inspection department .

7.As to the problem in the tooling manufacture process. main department will  organize discussion and solution.

4.Competitive quality will be checked anytime.and on-time delivery will be guarantee.

5. Safe packing and some parts of extra free .

6.reasonable min order quantity.

Picture display

1. Sodick EDM machine .

2. kinds of punch press manchine.

3. Sodick slow wire cut process details

4. small-scale grinding machine.

5. CNC process center

1.punching center.( kinds of  Ton to suit of customer requires)

2.automatic large-scale grinding machine.

3.220 Ton Taiwan TJSH punching machine.

4. Machine processing center.( stamping die assembly center)
